TruTool TSC 100

Your specialist for clean slats

With the TruTool TSC 100, you can clean your slats quickly and effortlessly. This ensures reliable, high-quality production of laser-cut components. The slats do not need to be removed for cleaning. This is practical and saves you time. It takes approximately 30 minutes to clean an entire standard size pallet of 1500 mm x 3000 mm.







Kategori:

Product Description

Simultaneous cleaning and production
On a laser cutting machine with pallet changer, you can clean the slats even during the cutting process.

Outstanding cleaning results
With the TruTool TSC 100, you can thoroughly remove the accumulation of slag, even on slats subject to high loads.

1-man operation
With the long machine handle and good machine handling, you can clean the slats effortlessly by yourself.

TruTool TSC 100, dimensional drawing













Cleaning tool

Selecting the right tool means minimal effort during cleaning, helping you to achieve optimal cleaning results.













Application

The TruTool TSC 100 can be used on virtually all CO2 and SSL 2D laser cutting machines

Technical data

Scope of delivery



The following consumables and the corresponding accessories are included in the scope of delivery.



TruTool TSC 100, Reinigungswerkzeug No. 3
Cleaning tool no. 3 incl. seal (integrated)

3 – 3.9 mm
Set of 2 1644868

Zubehör Standbild
Transport device

1 unit 1634956

TruTool TSC 100, Distanzplatte
Spacer plate (integrated)

1 unit 1734714

TruTool TSC 100, Dichtung mit Funktionsüberwachung
Seal with functional monitoring feature (1x integrated, 1x included in delivery)

1 unit 2046587

Gleitblech
Slide plate

1 unit 1619017

Zubehör Standbild
Allen wrench 4 mm

1 unit 0369003

Zubehör Standbild
Allen wrench 6 mm

1 unit 1640682



Accessories

Find the right consumables and accessories for your machine here.





TruTool TSC 100, cleaning tool No. 2
Cleaning tool No. 2

For strip thickness 2 – 2.9 mm incl. seal

Set of 2 1644868
TruTool TSC 100, cleaning tool No. 3
Cleaning tool No. 3

For strip thickness 3 – 3.9 mm incl. seal

Set of 2 1644867
Still image of accessories
Transport device
1 unit 1634956
TruTool TSC 100, seal
Seal
1 unit 1633583
Still image of accessories
Set

4 x sliding disk and 2 x seal

Set of 1 1681498
TruTool TSC 100, spacer plate
Spacer plate

If the height difference between the cross slat and slat is less than 60 mm

1 unit 1734714
TruTool TSC 100, Dichtung mit Funktionsüberwachung
Seal with functional monitoring feature
1 unit 2046587
